Plovák Patrik Slalom GBM

Kód: 5472/87 5472/92 5472/95 5472/100 5472/110 5472/115 5472/125 5472/130 5472/140 Zvolte variantu
5 hodnocení
Značka: Patrik
49 000 Kč
NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU NA OBJEDNÁVKU Zvolte variantu
Litráže
Zvolená varianta není k dispozici. Reset vybraných parametrů.
Můžeme doručit do:
30.9.2019 30.9.2019 30.9.2019 30.9.2019 30.9.2019 30.9.2019 30.9.2019 30.9.2019 30.9.2019 Zvolte variantu

HIGHEST PERFORMANCE WITH HIGHEST CONSISTENCY IS THE KEY TO SUCCESS!



Detailní informace

Detailní popis produktu

slalom_

Our slalom models are well known for their performance and consistency. It is important that all sizes perform equally and that there are no big weaknesses. It makes the size choice and gear setup easy and depending on the sail performance and the sailing style every size can be individually trimmed more into the performance direction needed. With adapting the cutouts from the smallest 3x sizes all shapes are 100% in line not only performance wise but also optically and it makes us proud to present such a harmonic high performing range.


IMG_9281-copy_RZ-1030x687

SHAPE DETAILS

Scoop-Rocker-Line

The bottom curve is designed to glide as low and smooth as possible over the water but still have enough height under the mast track area and at the nose so as not to stick to the water or dive into the upcoming chop.

Slalom 87 v3 and 92 v3 The performance ratio is designed for more control, which improves both top speed in rough conditions and enables easier gybing.

Slalom 95, 100 v3, 110 v3 and 115 v4 The performance ratio is designed to have increased acceleration and top speed.

Slalom 125, 130 and 140 The performance ratio is designed for earlier planning and acceleration.

Outline

Slalom 87 v3 and 92 v3 A relatively straight curve in the mid section with a narrow tail for ultimate control and maximum speed in rough conditions.

Slalom 95, 100 v3, 110 v3 and 115 v4 A relatively straight curve in the mid section with a narrow tail for ultimate control and maximum speed in rough conditions.

Slalom 125, 130 and 140 The round outline makes the board both agile and direct, which is important in the light wind for the quickest possible acceleration and to reach top speeds without losing the drive in the lulls. The SL 130 and 140 have a wider tail deck outline than the bottom, which helps the rider to have more leverage over the fin, but still have a narrow enough tail underneath for top speed.

Bottom Shape

Slalom 87 v3, 92v3, 95, 100 v3, 110 v3, 125 Flat panel Vee in the tail to the mid section for control and speed. The front section has an increasing Vee shape with double concaves and side flats for a smoother ride and to give the rails more height to clear the water whilst fully planing.
Slalom SL 115v4, 130, 140 Invert V in the tail which gives more lift for better planing and more acceleration. Flat panel V starts under the front footstrap and runs into an increasing Vee shape with double concaves and side flats for a smoother ride and to give the rails more height to clear the water whilst fully planing.

Deck Shape

S-Deck: Lower back foot, higher front foot and lower mast track allow a comfortable sailing position and outstanding control during cross and down wind reaches.

Slalom SL 87 v3, 92 v3 Slight dome in the deck to maintain volume whilst still having the deck as flat as possible to increase responsiveness to foot pressure for easier and more controlled jibing.

Slalom 95, 100 v3, 110 v3, 115 v4 and 125, 130, 140 A flatter deck makes the board responsive to foot pressure for easier and more controlled gybes.

Rail Shape

Nice boxy rails in the tail area for a comfortable foot position in the straps. Boxy rails in the mid section to avoid the water sucking up the deck and to provide flotation throughout and after the jibes. Thin rails in the nose area to reduce weight and gain on reactivity.

Cutouns

Refined rail and tail cutouts which have been gradually calculated in order that every board feels similar and just changes in volume. The smaller tail surface reduces drag and trims the board in a more lateral free gliding position whereas the rail cutout trims the board more to the leeward side which helps to release the upwind water pressure and increases acceleration and top speed.




CONSTRUCTION

With our additional GET line, we respond to the constant request for a softer construction and offer a more comfortable ride next to our sporty line. Our GBM line is the stiffer and lighter construction using materials with a higher Carbon percentage while our GET line offers more flex and comfort with the softer fiberglass material.

GBM – The full deck Carbon Biax with the full Carbon UD bottom is the construction combination to have a lightest and stiffest board for maximum early planning, acceleration and riding agility.

GET – The full deck Carbon Biax with the full fiberglass bottom is the combination of lightweight, stiffness and flex for early planning, acceleration and control.

CONSTRUCTION Composite Semi Custom Sandwich
CORE MATERIAL EPS (Styrofoam)
SANDWICH MATERIAL PVC

Sailing_leMourne_PD_1-1030x773
DIMENSIONS

  LENGTH
[MM]
WIDTH
[MM]
VOLUME
[LITRE]
TAIL WIDTH
AT 300
[MM]
NOSE WIDTH
AT 2000
[MM]
WEIGHT
(+/-6%)
[KG]
STRAP
OPTIONS &
INSERT HOLES
STRAP
QUANTITY
FIN BOX APPROVED
SERIES
SLALOM 87 III 2370 570 87 357 446 GBM: 5,4
GET: 5,5
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 92 III 2335 595 92 396 464 GBM: 5,6
GET: 5,7
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 95 2314 622 95 411 482 GBM: 5,7
GET: 5,8
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 100 III 2330 645 100 421 501 GBM: 5,9
GET: 6,0
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 110 III 2328 682 110 451 538 GBM: 6,2
GET: 6,3
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 115 IV 2338 698 115 488 556 GBM: 6,3
GET: 6,4
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 125 2302 772 125 544 594 GBM: 6,8
GET: 6,9
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 130 2288 808 130 564 607 GBM: 7,1
GET: 7,2
6X4 4 Deep Tuttle Foil Box PWA / ISAF
SLALOM 140 2288 848 140 606 643 GBM: 7,3
GET: 7,4
6X4 4 Deep Tuttle Foil Box PWA / ISAF

* The indicated weight is measured without footstraps.

RANGE OF USE

  BEST
SAIL SIZE
[M2]
SAIL
RANGE
[M2]
REC.
FIN SIZE
[MM]

FIN NOT INCLUDED
FIN
RANGE
[MM]
SLALOM 87 III 5.0-6.3 4.0-7.0 Carbon 300 260-340
SLALOM 92 III 5.6-6.8 4.5-7.0 Carbon 320 280-350
SLALOM 95 5,6-7,0 5,0-7,3 Carbon 340 280-360
SLALOM 100 III 5.8-7.3 5.5-7.8 Carbon 350 300-380
SLALOM 110 III 6.3-8.0 6.0-8.2 Carbon 380 340-400
SLALOM 115 IV 6.8-8.2 6.2-8.6 Carbon 390 350-410
SLALOM 125 7.3-8.6 6.8-9.0 Carbon 430 400-460
SLALOM 130 7.8-9.2 7.3-9.5 Carbon 450 420-480
SLALOM 140 8.4-9.6 7.8-10.0 Carbon 470 440-520

K16_sl_Julien_Quentel_s-1030x686

Doplňkové parametry

Kategorie: SLALOM, 87 l
Rok výroby: 2019
