GLIDE WIND is our friendly, easy-cruising and carving foil, also suitable for wave riding and basic freestyle moves. Ever dreamed about foiling but felt that it might be too dangerous or difficult? GLIDE WIND is the perfect tool to get you into foiling.
The lowest possible speed is required to take-off allowing first time foilers to feel safe and comfortable. This all-round foil focuses on extreme stability and early flying. It is designed with round edges on the wings for safety, and has been engineered to prevent catapults and to allow soft landings.

Detailní informace

Detailní popis produktu

glide wind plachta neilpryde rs windsurfing karlin

Technology

BASE SYSTEM

New CNC reinforced base construction.
Two deep titanium vertical tube connections to the mast for maximum strength, eliminating movement and offering perfect load transfer. Avoids vibration around the upper attachment area. Initially mounted with a Powerbox base system.

BASE SYSTEM neilpryde wind glide karlin 2020



CONSTRUCTION

All foils are supplied with a T-40 torx drive, and come with titanium plated stainless steel bolts for maximum strength to weight ratio, preventing any corrosion problems.

CONSTRUCTION neilpryde glide wind karlin 2020



TAIL WING ADJUSTMENT - NEUTRAL

Across our foils, the tail wings are there to deliver inverted thrust to balance the main wings to ensure stability and control. The foils come with a standard neutral tail wing setting.

TAIL WING ADJUSTMENT  NEUTRAL  glide windsurfing 2020



TAIL WING ADJUSTMENT - DOWN TILTED

A down-tilted setting ensures higher stability and more control in lighter winds, it naturally lifts the foil more and increases the low-end power. This setting is also a go-to when you are a heavier rider.

TAIL WING ADJUSTMENT  DOWN TILTED windsurfing karlin neilpryde 2020



TAIL WING ADJUSTMENT - UP TILTED

An up-tilted setting will help to reduce drag and lift, by up-tilting the tail wing setting, this can also be of benefit to lighter riders or in heavier wind conditions.

TAIL WING ADJUSTMENT  UP TILTED windsurfing karlin neilpryde 2020



MAST

80 cm aluminum mast. Optimized structure with two CNC female base system inserts ensuring maximum strength.
Hollow construction to reduce weight combined with x3 vertical cross-ribs for maximum stiffness. Sanded mast trailing edge to avoid planning turbulence noise. Tempered, salt water corrosion resistant 6061-T6 aluminum.

MAST karlin neilpryde glide wind tuttle box



WIND FUSELAGE

Perfectly blended wing to CNC machined fuselage connection and integrated wind fuselage providing minimum drag. Volume and weight of the aluminum used in the fuselage is reduced by eliminating the forward protruding nose.

WIND FUSELAGE windsurfing karlin 2020

WINGS

GLIDE wings are made of pre-preg carbon layup with inner foam construction for maximum durability to weight ratio. This setup creates a natural tendency to roll into turns maintaining a nice balance during your ride.
The front wing is designed with a pronounced rounded “angle of attack” and an elliptical bend shape. While flying, this thick leading edge on the front wing naturally closes the radius of your turn, tightening it. Far back, the angled down tail wings maintain a self- stabilizing roll allowing an easy turning performance.
During this momentum, the GLIDE tail wing will always come back to a flat position, stabilizing the turn.

WINGS windsurfing glide wind karlin neilpryde 2020

SPARE PARTS

Alternative boxes available - SURF BOX, DEEP TUTTLE, POWERBOX.

GET YOUR SPARE PARTS HERE
SPARE PARTS windsurfing karlin



glide foil box tuttle neilpryde 2020 windsurfing karlin

FOIL PROGRAMME

Want to learn more about our Foil programme and compare all our foils?

LEARN MORE

FOIL COMPATIBILITY

Click below to read all about the inter-compatibility of our foil range.

ČÍST VÍC

 obrazek glide wind S a M size neilryde 2020

GLIDE WIND SPECS

WING SPAN CM SPAN IN CHORD LENGTH CM CHORD LENGTH IN TOP AREA CM2 TOP AREA CM2 BOTTOM AREA CM2 BOTTOM AREA IN2 PROJECTION AREA CM2 PROJECTION AREA IN2
Front wing S 63.6 25.0 22.0 8.7 1148.0 177.9 1044.8 161.9 1045.0 162.0
Front wing M 74.9 29.5 22.6 8.9 1370.9 212.5 1310.4 203.1 1262.7 195.7
Front wing HP M 80.2 31.6 20.7 8.1 1302.5 201.9 1256.1 194.7 1230.1 190.7
Front wing L 85.8 33.8 23.1 9.1 1602.2 248.3 1537.4 238.3 1484.7 230.1
Front wing XL 100.0 39.4 24.0 9.4 2083.4 322.9 2029.0 314.5 1963.7 304.4
Tail wing S 39.5 15.6 7.7 3.0 245.4 38.0 248.5 38.5 230.5 35.7
Tail wing L 51.0 20.1 8.0 3.1 330.3 51.2 336.3 52.1 316.7 49.1
